Lithium battery selection directly impacts product safety, runtime, environmental adaptability, and service life. This document lists the technical specifications that must be verified when procuring or customizing lithium batteries, applicable to both single cells and battery packs (including protection circuit modules).

PTPbattery recommends integrating this checklist into your supplier evaluation process.

4. Safety & Compliance (Mandatory)

• Transport Safety: UN38.3

• Cell Safety: UL 1642 / IEC 62133 / GB 31241 (China)

• Pack Safety: UL 2054 / IEC 62133-2

• Environmental Compliance: RoHS, REACH

• Chemical Documentation: MSDS

• Protection Circuit Functions: Overcharge, over-discharge, overcurrent, short circuit, temperature protection (NTC)

PTPbattery emphasizes that no battery shipment should be accepted without valid safety certificates.

5. Mechanical & Assembly Information

• External dimensions and tolerances (especially thickness expansion allowance for pouch cells)

• Lead/tab configuration (wire, nickel tab, connector model)

• Form factor (cylindrical, pouch, prismatic)

6. Procurement Deliverables Checklist

Suppliers must provide, but not be limited to:

1. Official datasheet (including test conditions)

2. Batch test report (voltage, IR, capacity)

3. Safety certificate copies (scanned)

4. Batch traceability and management plan

5. Quality agreement (including defect rate and warranty period)

7. Common Risk Warnings

• Actual capacity under high-rate discharge can be significantly lower than rated capacity

• Usable capacity and discharge capability drop sharply at low temperatures

• Inconsistent IR within battery packs accelerates whole-pack failure

• Used or salvaged cells have no reliable life data

For lithium battery selection evaluation tailored to your specific application (energy storage, robotics, portable devices, medical instruments), please contact our technical team at info@ptpbattery.com

PTPbattery – Your trusted partner in battery & power solutions.
